Type:HEV-750D DC Voltage Checker for Electric Vehicle

DC 12V〜750V Audio-signaling and light emitting For electric vehicle and hybrid vehicle Alkaline Button Cell Battery 1.5V (LR44) x2

Type:HT-680D/HT-680DS Low Voltage Detector

AC 50V〜600V (50Hz/60Hz) DC 50V〜600V Audio-signaling and light emitting HT-680D :Conductive rubber HT-680DS:Metal LR44(1.5v) × 2 pcs

Type:HT-680DB/HT-680DBS Low Voltage Detector

AC 50V〜600V (50Hz/60Hz) DC 12V〜600V Audio-signaling and light emitting HT-680DB :Conductive rubber HT-680DBS:Metal LR44(1.5v) × 2 pcs

Type:HT-670 Low Voltage Detector

AC 50V〜600V (50Hz/60Hz) DC 50V〜600V Audio-signaling and light emitting When connected with lead wires. 100V LED comes on:AC,DC 30V±20V 200V LED comes on:AC,DC 140V±30V LR44(1.5V) × 2 pcs

For high to low voltage

Type:HSF-7 High and Low Voltage Detector

AC 80V〜7000V (50Hz/60Hz) Audio-signaling and light emitting R03(1.5V) x 2 pcs



Type:HSE-7T1 High and Low Voltage Detector

AC 80V〜7000V (50Hz/60Hz) Audio-signaling and light emitting LR44(1.5V) x 2 pcs



Type:HSE-7G High and Low Voltage Detector

AC 60V〜7000V (50Hz/60Hz) Audio-signaling and light emitting LR44(1.5V) x 2 pcs

•

Type:HSS-6B　High and Low Voltage Detector

AC 80V〜600V (50Hz/60Hz) Detect holding nameplate portion. AC 3000V〜25000V (50Hz/60Hz) Detect holding the grip. Audio-signaling and light emitting LR44(1.5V) x 2 pcs



Type:HSG-6 High and Low Voltage Detector

AC 80V ～ 7000V (50Hz/60Hz) Audio-signaling and light emitting LR44(1.5V) × 2 pcs



Type:HSN-6A High and Low Voltage Detector

AC 100V〜7000V (50Hz/60Hz) DC 50V〜7000V Audio-signaling and light emitting May be used for voltage detection of a low-voltage circuit if holding the name plate of hte detecting part. LR44(1.5V) x 2 pcs



For high voltage to special high voltage

Type:HST-30 High and Special High Voltage Detector

AC 3kV - 34.5kV (50Hz/60Hz) FRP is used for the insulating stick. It is of lightweight and has outstanding operability. Tip metal fitting consists of a shock-absorbing spring. LR44(1.5V) x 2 pcs



Type:HST-20N High and Special High Voltage Detector

AC 3kV - 25kV (50Hz/60Hz) DC 3kV - 25kV Non Ball joint Audio-signaling and light emitting LR44(1.5V) x 2 pcs



Type:HS-90N High and Special High Voltage Detector

AC 6kV - 90kV (50Hz/60Hz) DC 6kV - 90kV Non Ball joint Audio-signaling and light emitting 6R61 or 6F22(9V) × 1 pcs



For special high voltage

Type:HST-70 Special High Voltage Detector

AC 20kV - 80.5kV (50Hz/60Hz) FRP is used for the insulating stick. It is of lightweight and has outstanding operability. Tip metal fitting consists of a shock-absorbing spring. LR44(1.5V) x 2 pcs



Type:HST-170 Special High Voltage Detector

AC 60kV - 195.5kV (50Hz/60Hz) FRP is used for the insulating stick. It is of lightweight and has outstanding operability. Tip metal fitting consists of a shock-absorbing spring. LR44(1.5V) x 2 pcs



Type:HST-250 Special High Voltage Detector

AC 150kV - 287.5kV (50Hz/60Hz) FRP is used for the insulating stick. It is of lightweight and has outstanding operability. Tip metal fitting consists of a shock-absorbing spring. LR44(1.5V) x 2 pcs



Type:HS-500 Special High Voltage Detector

AC 250kV - 550 kV (50Hz/60Hz) Non Ball joint Audio-signaling and light emitting 6R61 or 6F22(9V) x 1 pcs

•


For railways

Type:HVC-1.5N2 Voltage Detector for DC Overhead contact lines

Voltage Detector for DC 1500V trolley wires Audio-signaling and light emitting R6 or LR6(1.5V) × 4 pcs



Type:HST-1.5N High Voltage Detector

AC 600 V - 7kV (50Hz/60Hz) DC 600 V - 7kV Non Ball joint Audio-signaling and light emitting LR44(1.5V) x 2 pcs



Type:HS-1.5NJ High Voltage Detector

AC 6kV - 7kV (50Hz/60Hz) DC 600V - 7kV Non Ball joint Audio-signaling and light emitting 6R61 or 6F22(9V) × 1 pcs



Type:HS-1.5NR High Voltage Detector

AC 6kV - 7kV (50Hz/60Hz) DC 1kV - 7kV Non Ball joint Audio-signaling and light emitting 6R61 or 6F22(9V) × 1 pcs



Type:HST-W80JS Special High Voltage Detector

AC 20kV - 80.5kV (50Hz/60Hz) Audio-signaling and light emitting LR44(1.5V) x 2 pcs
